Rhino Blade™ Pull Dozer Specifications

BUILT FOR HIGH-HORSEPOWER WORK

Rhino Blade™ is engineered for 500+ HP tractors and demanding agricultural and industrial earthmoving. Its 32,750-lb build, 265-inch maximum working width, steerable tires and patented Dynamic Wings provide the strength and control needed for levelling, ditching, grading, ripping and material moving.

Total Side to Side Tilt
12.2 deg
Total Blade Roll
50.5 deg
Blade Angled Back
26.6 deg
Blade Angled Forward
85.1 deg
Transport Width
191 in.
Widest Working Width
265 in.
Middle Blade Width
144 in.
Overall Length
421 in.
HP Rating
500+
Machine Weight
32,750 lbs
Warranty
2 Year Warranty
Key Functions
Shape, Move, Level, Ditch, Rip, Grade
Tires
1000/50R25 High-Flotation Tires
Blade Position Indicators
3 Large Blade-Position Indicators
Valve Block Area
Illuminated Under the Hood
Steering
Steerable Tires for Sharp Turns and Tractor Offset
Rippers
Integrated Rippers
Construction
Heavy-Duty Box Frame Blade and Main Frame
Dynamic Wings
Patented Wings Roll Forward for Carrying Material and Fold for Transport
GPS Mount
Standard GPS-Ready Bracket with Dedicated Work Light
Main Hitch Tube
Heavy-Duty 16 × 16 × 1/2 in. Hitch Tube
Adjustment Bracket
Colour-Coded Hole Organization Bracket
Receiver Hitch
Category 5 Receiver Hitch

Built for 500+ HP Agricultural Tractors

Rhino Blade™ is designed to harness the power of modern high-horsepower tractors. Its heavy machine weight, high-flotation tires and steerable configuration provide stability and control across demanding agricultural and earthmoving applications.

Working and Transport Dimensions

A maximum working width of 265 inches provides broad coverage for land levelling and material moving. For transportation, the patented Dynamic Wings fold to reduce the machine to a width of 179 inches.

Have Questions About Tractor Compatibility?

Contact Rhino Blade™ with your tractor make, model and horsepower rating to discuss compatibility and intended applications.
